Square Poles

Square Street Light Poles


ORBIX's expertly designed square poles are perfect for delivering secure and efficient lighting solutions for our clients' needs. Our innovating concept of square lighting poles is suitable for the construction of powerful floodlights. Our square poles can be seen at many places, including parking lots, parking fields, hospitals, sporting facilities and shopping malls with a height range of 2 and 15 meters, with high standards of resilience. Due to their improved durability, our square poles can also be used as high-efficiency camera poles up to 5 meters long.

Square Composite Poles provide a creative approach to the rigorous lighting requirements that boost architecture today. Architects, engineers and designers admire their futuristic style.
All ORBIX-manufactured square poles come with a number of superior and exclusive features and optional accessories. All our engineered square poles are designed and tamper-resistant to meet UAE national standards. Please feel free to contact us today to clarify your specifications for square poles.

Specifications

  • SHAFT
  • MATERIAL: EN S355J0
  • TENSILE STRENGTH: 470 MPa
  • BASE PLATE
  • MATERIAL: JIS G3101 SS400
  • TENSILE STRENGTH: 400 MPa

Dimensions

  • Pole Height: 2 Meter - 10 Meter
  • Pole Thickness(mm): 2-6
  • Base Plate Thickness(mm): 12-25
  • Base Dimension(mm): 200X200-400X400
  • Shaft Dimension(mm): 45-300
  • Cutout Dimension(mm): 100X250-250X600

Pole Finish

  • HOT DIP GALVANIZING
  • ASTM A123 and A385
  • POWDER COATING
  • EPOXY AND EPOXY POLYESTER COATING
  • PAINT FINISH
  • DUPLEX COATING (ALL SOLID COLORS)
